What is K-Tag?

K-Tag is a new stand alone unit with the ability to tune a vast number of vehicle for the first time!

K-Tag also offers tuning for motorbikes, jet ski’s, marine and TuneProtect vehicles.



These new options will allow the us to tune a vast number of Japanese performance vehicles such as Nissan (Skyline & 350Z), most Honda vehicles, Hyundai & Subaru.



The ECU will need to be removed and workedon, on a dedicated workbench. As well as this, K-Tag will also combine the new ECU’s that hold the Anti-Tuning protocols. This will allow you to tune ECU’s from 2009/10 onwards that are unable to be tuned through the OBD Diagnostic port, aka TuneProtect ECUs, locked at factory level.



Also available with K-Tag is the option to return to BDM tuning. This covers vehicles that do not have a K-Line Communication between the ECU and OBD port such as Mercedes AMG models and Ford ST models not covered through the OBD.



At a glance these are just some of the ECU’s covered by K-Tag

BDM MOTOROLA MPC5xx

BOSCH EDC16
BOSCH EDC16+
BOSCH EDC7
BOSCH ME9.2
DELPHI DCM
DELPHI DCM3.2
MARELLI Z13DTJ
MOTOROLA CM850
PHOENIX L14/L15
PHOENIX L16
PHOENIX L4
SIEMENS MS45
SIEMENS MSS70
SIEMENS MSV70
SIEMENS PPD1.5
SIEMENS PPD1.XX
SIEMENS SID 20X
SIEMENS SID 30X
SIEMENS SID 80X
TRW EMS2
TRW EMS2 DXI12

J-TAG NEXUS MPC5xx

DELPHI DCM3.5 – MERCEDES CDI
MARELLI 7GF
MARELLI 8GMF
MARELLI MJ8DF

J-TAG RENESAS SH705x

DELPHI DCM3.4
DENSO 1.7
DENSO 062J0
DENSO 4D56
DENSO D3
DENSO KS
DENSO R2AX
DENSO RF8G
SAGEM 3000
SIEMENS SIM32
VALEO V40

BOOTLOADER MITSUBISHI MH72xx/MH8xx

MITSUBISHI MH72XX

BOOTLOADER INFINEON TRICORE

BOSCH EDC17
BOSCH MED17.3.1
BOSCH MED17.4/MEV17.4
BOSCH MED17.X CAN
BOSCH MED17x/MEV17x
BOSCH MEV1746

BOOTLOADER ST10

BOSCH ME7.1
BOSCH ME7.1.1
BOSCH ME7.9.10

Many more vehicles are being added to the application list on a weekly basis, and the list above is not exclusive, merely a glimpse at what can now be tuned, please contact us if you are unsure about your vehicle, but one thing to remember is that K-Tag is not tuning through the OBD port……for that we still have our Kessv2 OBD Re-Mapping equipment to count on!



Our standard price for K-TAG Re-Mapping is £299

This process MUST be carried out at our workshop, we are unable to offer a mobile service because of the technical process required to 'bench tune' vehicles of this nature.

We require the vehicle for 1 business day - should it be completed sooner, we can arrange for you to collect, or us to deliver your vehicle back to you sooner.

All maps are carried out by our fully qualified senior technician, fully insured and Good Garage Scheme accredited.
